Products

32/50 GHz DSO, 30.2 GBd, 2 channel BERT 1 channel DSO with jitter injection, BERT: NRZ, Scope: PAM4/NRZ

BERT and DSO with jitter generation in one. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 32 GHz Electrical DSO. External Ref Clock Input. Air-tight and robust shell.

Standard cPCI 6U Chassis. 4-Slot Backplane.

For use with cPCI Boards (ML4025, ML4039, etc..)

Standard cPCI 6U Chassis. 8-Slot Backplane.

For use with cPCI Boards (ML4025, ML4039, etc..)

Low Cost NRZ Jitter Generator.

For use with ML4039 & ML4039B

Adds capabilities for GPON, EPON, 10GPON testing. 2 Filter inputs and outputs accessible from the faceplate. A Burst control signal generator for asymmetric PON CDR mode for the DSO

Options Listed below…

1-16.2 Gbps BERT dual-channel

One channel with 2.92mm connectors and one channel SFP

Replace SFP28 with XFP

-

10GHz ref optical receiver+DSO.

Can be ordered alone

25GHz reference optical receiver+DSO.

Can be ordered alone

32GHz electrical DSO.

Can be ordered alone

Custom Filter _____GHz BW

SPECIFY BANDWIDTH – besides the built-in LPFs for 1.25G, 2.5G and 10G, a customer can order a custom filter at any bandwidth below 10 GHz. This filter comes implemented on a daughter card that plugs into the Instrument.

31.5Gbps BERT

(pre-requisite option: B16, $7.5k)

High Voltage (4-8 Vpp diff)

Pre-requisite option B16 ($7.5k) or B32 ($7.5k+$6.5k)

NRZ BERT + 32GHz DSO

BERT and DSO in One. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 32 GHz Electrical DSO. External Ref Clock Input. Air-tight and robust shell. Low Cost.

NRZ BERT + 50GHz DSO

BERT and DSO in One. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 50 GHz Electrical DSO. External Ref Clock Input. Air-tight and robust shell. Low Cost.

NRZ BERT + 32GHz DSO w/Jitter Generation

BERT and DSO with jitter generation in one. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 32 GHz Electrical DSO. External Ref Clock Input. Air-tight and robust shell. Low Cost.

NRZ BERT + 50GHz DSO w/Jitter Generation

BERT and DSO with jitter generation in one. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 50 GHz Electrical DSO. External Ref Clock Input. Air-tight and robust shell. Low Cost.

NRZ BERT + 50GHz DSO w/Jitter Generation

BERT and DSO with jitter generation in one. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 50 GHz Electrical DSO. External Ref Clock Input. Improved signal integrity of the DSO. SJ FM circuit implemented.

PAM4/NRZ 30Gbd BERT + 32GHz DSO

PAM4 BERT and DSO with jitter generation in one. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 32 GHz Electrical DSO. External Ref Clock Input. Air-tight and robust shell. Low Cost.

PAM4/NRZ 30Gbd BERT + 50GHz DSO

PAM4 BERT and DSO with jitter generation in one. Ultra Compact Stand Alone. Data Rates: 3.1-5 Gbps, 6.2-15 Gbps, 18.5-30.2 Gbps. 50 GHz Electrical DSO. External Ref Clock Input. Air-tight and robust shell. Low Cost.

32GHz Digital Sampling Oscilloscope

Digital Sampling Oscilloscope. Ultra Compact: Stand Alone. 32 GHz Electrical DSO. Processing of NRZ and PAM4 data. Air-tight and robust shell. Low Cost.

50GHz Digital Sampling Oscilloscope

Digital Sampling Oscilloscope. Ultra Compact: Stand Alone. 50 GHz Electrical DSO. Processing of NRZ and PAM4 data. Air-tight and robust shell. Low Cost.

4 CH, 32GHz DSO, cPCI form factor

DSO: 4-lane channel. Super Slim: 1 slot cPCI. 32 GHz Electrical DSO. NRZ and PAM4 modes. Low Cost. See if customer needs ML4000-4 or ML4000-8 Chassis with this

4 CH, 50GHz DSO, cPCI form factor

DSO: 4-lane channel. Super Slim: 1 slot cPCI. 50 GHz Electrical DSO. NRZ and PAM4 modes. Low Cost. See if customer needs ML4000-4 or ML4000-8 Chassis with this

4 CH, DSO w/ TDR Capability, cPCI form factor

DSO with TDR capability – 4 channels differential. 4 separate CW outputs for THD measurements
Frequency domain measurements: RL and IL and THD
Time domain measurements: TDR/TDT/Impedance, eye and pattern measurements, jitter decomposition, filtering and equalization. Single-ended outputs available. A 2-lane variant available — price upon request. See if customer needs ML4000-4 or ML4000-8 Chassis with this. Recommend the ML4035-BTP for new orders.

4 Lane, 30Gbps NRZ BERT, cPCI Form Factor

BERT: 4-lane up to 30Gbps. 4 slot cCPI. Data Rates: 8.5-15 Gbps and 21-30 Gbps. See if customer needs ML4000-4 or ML4000-8 Chassis with this. Recommend the ML4039-BTP for new orders.

4 Lane, 1-30Gbps NRZ BERT, cPCI Form Factor

BERT: 4-lane up to 30Gbps. 4 slot cCPI. Data Rates: 1-30 Gbps. Low Cost. See if customer needs ML4000-4 or ML4000-8 Chassis with this. Recommend the ML4039B-BTP (Gen2) for new orders.

4 Lane, 30Gbps NRZ BERT w/ Jitter Gen., cPCI Form Factor

BERT: 4-lane up to 30Gbps for jitter/receiver tolerance featuring programmable. Output amplitude control. 4 slot cCPI. Data Rates: 8.5-15 Gbps and 21-30 Gbps. Low Cost. See if customer needs ML4000-4 or ML4000-8 Chassis with this.

4 Lane, NRZ BERT w/ Jitter Gen, ATE Form Factor

BERT: 4-lane up to 30Gbps for jitter/receiver tolerance featuring programmable output amplitude control.ATE friendly. Data Rates: 8.5-15 Gbps and 21-30 Gbps. Low Cost. See if customer needs SMPM to K or other cables…?

4 Lane, PAM4/NRZ BERT, ATE Form Factor

4-Lane BERT as
4x 30Gbps NRZ
or
4x 60Gbps PAM4
